Load capacity/rated load(kg) :
1500
Load centre distance(mm) :
400
Fork height,lowered(mm) :
97
Height,mast lowered(mm) :
1940
Max.lift height(mm) :
1500
Height,mast extended(mm) :
2000
Overall lenght(mm) :
1350
Fork dimensions(mm) :
48/100/850
Width Overall forks(mm) :
980
Ground clearance,laden,below mast(mm) :
25
Aisle width for pallets 1000×1200 crossways(mm) :
2050
Aisle width for pallets 800×1200 lengthways(mm) :
2040
Turning radius(mm) :
1245
Lift speed,laden/unladen(mm/time) :
25
Lowering speed,laden/unladen(mm/s) :
Manual control
