Rich stacker model RSB13-850

___________________________
Capacity: 1300 Kg

Model :

RSB13

Configuration No :

850

Type :

Reach(Tilt,Side Shifter)

Mast type :

Standard-3-stages

Load capacity(kg) :

Load center(mm) :

500

Wheel base(mm) :

1478

Operating type :

Walkie

Wheels type :

Wheel quantity/Driving wheel/Balance wheel/Bearing wheel :

1/0/4

Reach distance(mm) :

0-550

Standard lift height(mm) :

3800/4000/4500/5000/55000

Max extended height(mm) :

4991/5191/5691/6191/6691

Mast lowered height(mm) :

1914/2081/2248/2415/2582

Lowered fork height(mm) :

Fork size(lenght/width/tickness)(mm) :

1070/100/40

Overal lenght(mm) :

2225

Overall width(mm) :

1430

Outside width between forks(mm) :

200-755

Tilt of fork(F/B)(mm) :

4/3

min tuning radius(mm) :

1566

Min Aisle width for pallets 800×1200(mm) :

2135

Min Aisle width for pallets 1000×1200(mm) :

2315

min ground clearance(mm) :

Travel speed,laden/unladed(km/h) :

3.5/4

Lift speed,laden/unladen(mm/time) :

130/150

Lowering speed,laden/unladen(mm/s) :

100/180

Gradeability,laden/unladed(%) :

3/5

Drive motor(kW) :

DC0.15

Lift motor(kW) :

DC3.0

Steering motor(kW) :

AC1.5

Battery voltage(V) :

Battery Capacity(Ah) :

345(Options:FAAM345)

Brake :

Electromagnetic/regenerative

Controller :

Curtis

Battery weight(kg) :

300

Service weight(with battery)(kg) :

2420

Distance Shift fork Side(mm) :

150
